Chronic Total Occlusion Guide Wires

ASAHI CHIKAI® 008 and ASAHI CHIKAI® 10

ASAHI Gaia® Series

Good choice for the need of high penetration while maintaining torqueability. Chronic Total Occlusion indicated. Guide wire with ACT ONE and low tip load to improve deflection and torqueability.

Tip Load

Tip Radiopacity15 cm
CoatingHYDROPHILIC* WITH UNCOATED DISTAL TIP
Hydrophilic 40 cm – uncoated distal tip
Tip Shape

Ordering Information

To order, please call us toll-free at 855-286-9473, or email us at customersupport@asahi-intecc.com. To see a complete listing of all available ASAHI products, go to our Full Product Listing page.

ProductCatalog No.Tip ShapeLength (CM)Diameter (INCH(MM))Radiopaque Segment (CM)Spring Coil Length (CM)Coating
ASAHI Gaia FirstAHW14R007PPre-Shape1900.010/0.014 (0.26/0.36)1515Hydrophilic* with Uncoated Distal Tip
ASAHI Gaia First, 300 cmAHW14R307PPre-Shape3000.010/0.014 (0.26/0.36)1515Hydrophilic* with Uncoated Distal Tip
ASAHI Gaia SecondAHW14R008PPre-Shape1900.011/0.014 (0.28/0.36)1515Hydrophilic* with Uncoated Distal Tip
ASAHI Gaia Second, 300 cmAHW14R308PPre-Shape3000.011/0.014 (0.28/0.36)1515Hydrophilic* with Uncoated Distal Tip
ASAHI Gaia ThirdAHW14R011PPre-Shape1900.012/0.014 (0.30/0.36)1515Hydrophilic* with Uncoated Distal Tip
ASAHI Gaia Third, 300 cmAHW14R311PPre-Shape3000.012/0.014 (0.30/0.36)1515Hydrophilic* with Uncoated Distal Tip
*Coated with SLIP-COAT® coating
Indications for Use

ASAHI PTCA Guide Wires are intended to facilitate the placement of balloon dilation catheters during percutaneous transluminal coronary angioplasty (PTCA) and percutaneous transluminal angioplasty (PTA). The ASAHI PTCA Guide Wires are not to be used in the neurovasculature.
